| Place of Origin: | China |
|---|---|
| Hàng hiệu: | DOOR or OEM |
| Chứng nhận: | CE / IS09001 |
| Model Number: | DR.TD6623 |
| Minimum Order Quantity: | 1 lane |
| Giá bán: | negotiable |
| Packaging Details: | wood carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 2500 sets per month |
| Material: | 304# Stainless Steel | Suitable For: | Access Control, Entrance And Exit Control |
|---|---|---|---|
| Turnstile Material: | SUS304 Stainless | Communication Interface: | RS485,dry Contact |
| Power Supply: | AC110/AC220+/-10% | Swing arm available: | Acrylics Or Tempered Glass |
| Driving Motor: | Servo Motor | Opening Signal Input:: | Dry Contact |
| Working environment: | -25℃-+70℃ | Pass speed: | 30-50p/m |
| Support System: | Face Recognition,ic/id Card,fingerprint | Motor: | Servo motor |
| IR Sensor: | 8 pairs | Passage Width: | Standard 600mm, max 900mm |
| IP Rating: | IP42 | Mean Cycles Between Failure: | 20 million times |
| Voltage: | AC110V/AC220V±10% 50-60Hz | Operating Power: | Single Core 100w, dual core 200w |
| Method of position: | Motor + clutch + encoder | Mtbf: | 10 Million Times |
| Size: | L1600×W160×H1030mm | Weight: | 80kg |
| Color: | Silver | ||
| Làm nổi bật: | 304 stainless steel speed gate,servo motor speed gate turnstile,face recognition speed gate turnstile |
||
| Attribute | Value |
|---|---|
| Material | 304# Stainless Steel |
| Suitable For | Access Control, Entrance And Exit Control |
| Turnstile Material | SUS304 Stainless |
| Communication Interface | RS485, dry Contact |
| Power Supply | AC110/AC220+/-10% |
| Swing arm available | Acrylics Or Tempered Glass |
| Driving Motor | Servo Motor |
| Opening Signal Input | Dry Contact |
| Working environment | -25℃-+70℃ |
| Pass speed | 30-50p/m |
| Support System | Face Recognition, ic/id Card, fingerprint |
| Motor | Servo motor |
| IR Sensor | 8 pairs |
| Passage Width | Standard 600mm, max 900mm |
| IP Rating | IP42 |
| Mean Cycles Between Failure | 20 million times |
| Voltage | AC110V/AC220V±10% 50-60Hz |
| Operating Power | Single Core 100w, dual core 200w |
| Method of position | Motor + clutch + encoder |
| MTBF | 10 Million Times |
| Size | L1600×W160×H1030mm |
| Weight | 80kg |
| Color | Silver |
Widely used for official or corporate buildings, sectioning off certain areas in hotels (gyms, spas), industrial buildings or offices.
Plywood case size: 167*35*114cm
G.W.: 85KG
Shipping fee and delivery date to be negotiated. Contact supplier for more details.
